DHX-Ⅱ
XINGLE
The Multi-Function Laboratory Automatic Ampoule Washing Machine is a high-efficiency cleaning system designed for pharmaceutical labs, research institutions, and testing centers. It is capable of automatically cleaning both the interior and exterior surfaces of various lab containers, including injection ampoules, oral liquid dropper bottles, vials (e.g., penicillin vials / Saelin bottles), and yellow round bottles.
Spray pressure: 0.2–0.3 MPa – effectively removes dust, dirt, particles, and stubborn residues.
Water flow velocity: 2–4 m/s – ensures strong flushing action on both internal and external surfaces.
Rotating cage speed: 10–520 RPM (adjustable).
Output capacity: 10,000–15,000 bottles/hour – ideal for labs with high container turnover.
Bottle height range: 30–120 mm.
Compatible with: water-injection ampoules, oral liquid bottles, vials (e.g., penicillin vials / Saelin bottles), and more.
Supports internal & external washing, spraying, and water spinning (drying) in one integrated process.
Fine washing tank and coarse washing tank – allows separate handling of different cleanliness requirements.
Automatic water refill function – monitors water level in real time and refills automatically to ensure uninterrupted operation, improving both efficiency and product quality.
| Production capacity | 10,000-15,000 bottles/hour |
| Motor total power | 1.5Kw 380V |
| Material | Stainless steel plate (304) High quality carbon steel |
| Overall dimensions | 900*1000*1750mm |
| Total Weight | 150KG |
| Cage speed | 10-520 rpm |
| Flushing pressure | 0.2-0.3MPa |
| Rinse water speed | 2-4m/s |
Chemical labs often use injection ampoules for packaging specialty reagents. This washer thoroughly cleans inner and outer walls, ensuring no residual impurities remain that could affect reagent purity.
Labs may prepare buffers, dyes, or other solutions stored in oral liquid bottles. The machine removes residues and contaminants, maintaining the purity of custom formulations.
Penicillin vials (Saelin / injectable vials) are commonly used to store drug samples, intermediates, or microbiological cultures. The washer provides rigorous cleaning to reduce contamination risk and ensure safe, reliable containers for sensitive experiments.
