XL-FBD-1.5
XINGLE
The material is suspended in a clean, hot airflow (negative pressure) to form a fluidized state. Its surface is fully in contact with the hot air, resulting in uniform heating and optimal heat exchange, resulting in extremely high efficiency. With a suitable spray system and further structural improvements, the fluidized bed becomes a multi-purpose process equipment capable of drying and granulating.
Industrial boiling granulator with a "top spray" system, this machine is primarily used for mixing, drying, and granulating operations in the pharmaceutical, food, and chemical industries.
Powdered materials for granulation are placed into the fluidized bed. Cold air enters through the heating chamber at the rear of the main unit, passes through primary and secondary filtration, and is heated to the required inlet temperature by the heater before entering the fluidized bed. The powder is fluidized within the bed. The granulation binder is pumped into a dual-fluid atomizer via an infusion pump, atomized, and sprayed onto the fluidized material. Powdered materials form bridges, aggregate, and grow into granules. Moisture evaporates and is carried out of the machine by the exhaust air.
(1) Granulation through powder improves fluidity and reduces dust flying.
(2) Granulation adopts heavy-weight method, which can be used for heavy-weight and light-weight granulation.
(3) Spraying, mixing, granulation and drying are carried out simultaneously, which greatly reduces the process.
(4) Special anti-static filter bags are used to prevent the occurrence of static electricity.
(5) There is a discharge hole on the top of the equipment to prevent the equipment from being damaged in the event of an explosion.
(6) Granulation is carried out in a sealed system, without leakage and dust flying.
(7) The equipment can be operated manually or automatically.
(8) The granulation process parameters are stable and the repeatability is extremely high.
(9) The equipment has no dead angles, fast unloading, easy flushing, and complies with GMP standards.
Main Application Areas of Boiling Granulators：
1. Pharmaceutical Industry: This is the primary application area. It is used for preparing tablet and capsule granules, and for drying and granulating Chinese herbal extracts.
2. Food Industry:Pharmaceuticals Granulator Machine is used for granulating milk powder, instant coffee, granular beverages, seasonings, food additives, etc.
3. Chemical Industry: Fluidized Bed Granulator is used for preparing dyes, pigments, catalysts, detergents, and plastic granules.
The material is suspended in a clean, hot airflow (negative pressure) to form a fluidized state. Its surface is fully in contact with the hot air, resulting in uniform heating and optimal heat exchange, resulting in extremely high efficiency. With a suitable spray system and further structural improvements, the fluidized bed becomes a multi-purpose process equipment capable of drying and granulating.
Industrial boiling granulator with a "top spray" system, this machine is primarily used for mixing, drying, and granulating operations in the pharmaceutical, food, and chemical industries.
Powdered materials for granulation are placed into the fluidized bed. Cold air enters through the heating chamber at the rear of the main unit, passes through primary and secondary filtration, and is heated to the required inlet temperature by the heater before entering the fluidized bed. The powder is fluidized within the bed. The granulation binder is pumped into a dual-fluid atomizer via an infusion pump, atomized, and sprayed onto the fluidized material. Powdered materials form bridges, aggregate, and grow into granules. Moisture evaporates and is carried out of the machine by the exhaust air.
(1) Granulation through powder improves fluidity and reduces dust flying.
(2) Granulation adopts heavy-weight method, which can be used for heavy-weight and light-weight granulation.
(3) Spraying, mixing, granulation and drying are carried out simultaneously, which greatly reduces the process.
(4) Special anti-static filter bags are used to prevent the occurrence of static electricity.
(5) There is a discharge hole on the top of the equipment to prevent the equipment from being damaged in the event of an explosion.
(6) Granulation is carried out in a sealed system, without leakage and dust flying.
(7) The equipment can be operated manually or automatically.
(8) The granulation process parameters are stable and the repeatability is extremely high.
(9) The equipment has no dead angles, fast unloading, easy flushing, and complies with GMP standards.
Main Application Areas of Boiling Granulators：
1. Pharmaceutical Industry: This is the primary application area. It is used for preparing tablet and capsule granules, and for drying and granulating Chinese herbal extracts.
2. Food Industry:Pharmaceuticals Granulator Machine is used for granulating milk powder, instant coffee, granular beverages, seasonings, food additives, etc.
3. Chemical Industry: Fluidized Bed Granulator is used for preparing dyes, pigments, catalysts, detergents, and plastic granules.
